OC-1 Ophthalmic Operator’s Chair

Category:
Ergonomics, functionality and comfort. OC-1 has been designed to ensure maximum comfort and functionality for the ophthalmic surgeons.

Product tech spec

OC-1 operator’s chair has been designed to ensure maximum comfort and functionality for the ophthalmic surgeons during cataract surgery and other procedures. It has been equipped with electrically elevated seat and ergonomically positioned foot switch for upward/downward movement, as well as manually adjustable backrest and armrests. A robust base has been equipped with 3 heavyduty castors for easy movement around the operation theatre, as well as with foot operated main break, and manually operated locking system. Battery pack has been provided.

Dimensions

Width 885 – 1 015mm
Depth 740mm
Height 835 – 1 110mm

Technical specification

Height adjustment range 550 – 750mm
Arm supports rotation range up to 126°
Armrest height adjustment 78mm
Backrest height adjustment 75mm
Backrest forward/backward adjustment 55mm
Input 100-240V AC, 50/60Hz
Battery pack 24V, 2.2Ah
Battery charging 24V ±0.5V, 1.2A
Working time up to 20h
Packaging 1 pallet, 120x80x160cm, ca. 85kg (gross)

AVAILABLE COLOURS
